dh/fr stem
had tried making a stem ( hand milled ) inspired by the TIOGA CUBE stem some 12-13 years back, while in college. i was quite successful with that other than the fact that i had miscalculated some measurements i had only enough space to drill a 2mm hole for the M6 bolt that i had initially thought of !
cut to present.
i finally made a CNC machined stem, designed in Solidworks.
made from T6-6082 alloy. heat treated to T6 after machining.
M6 hardware (finally !! haha)
0 deg rise. 50mm reach
anodized colors
weight is approx 230 grams including hardware.
laser engraving is in process as i type this.
in all, pretty much satisfied with the result other than a few extremely minor issues.
